Model Overview

HBML-3000C small door electronic Brucell hardness meter adopts advanced design concept, electromechanical aspects adopt the advanced technology in the field of hardness meter, accurate test results, strong value repeatability, high degree of automation, low labor intensity, small human error, beautiful appearance, is one of the advanced Brucell hardness meter in China.

This hardness meter can be used to determine cast iron, non-ferrous metals, annealing, conditioning and most of the supplied steel supply. At the same time, it is suitable for testing soft metals such as pure aluminum, copper, lead, tin, zinc and their alloys. Brinell hardness has high measurement accuracy, good recovery and representativeness. It is an indispensable hardness measurement instrument for mechanical metallurgy and measurement department.

Product Characteristics

• The fuselage and workbench adopt precision casting process, strong structure, rigid, accurate, reliable, durable;

• Portal rack, removable workbench

• The test mechanism adopts high precision spoke pressure sensor, and the loading device has built-in pressure sensor of 5 ‰. The test force value is accurate, stable and reliable, and has the function of automatic compensation of test force.

• Using the independently developed portal electronic Brinell hardness meter special CNC system, fast running speed, the full closed-loop gradient from fast to slow applied test force, to ensure that the test force applied smooth without impact;

• Using the contemporary advanced high-speed microprocessor, the instantaneous response is fast, to ensure that the test force accuracy is stable within ± 0.5%;

• Stepper motor, high precision ball screw and linear guide rail; accurate positioning, simple maintenance;

• Test force, load saturation time, feed speed and test speed can be artificially adjusted and controlled;

• The test process is automatic, with no one responsible for the operation error;

• Precision as per GB / T231.2, ISO 6506-2, and US ASTM E10.

Applied Range

This hardness meter can be used to determine cast iron, non-ferrous metals, annealing, conditioning and most of the supplied steel supply.

At the same time, it is suitable for testing soft metals such as pure aluminum, copper, lead, tin, zinc and their alloys.

Brinell hardness has high measurement precision, good recovery and representativeness, and is an indispensable hardness measurement instrument of mechanical metallurgy and measurement department.

Main Technical Parameter Sheet

Measurement Range: 32—650HBW

Test Force Levels: 750, 1000, 3000kgf (optional 187.5, 250, 500kgf)

Maximum Allowable Height Of Test Piece: 600mm (customizable)

Horizontal Movement Distance Of The Hardness Testing Mechanism: 200mm (customizable)

Distance Between The Two Columns: 640mm (customizable)

Power Supply: 220V, 50Hz

Dimensions: 1240×1000×2000mm (actual dimensions may vary)

Accessory Box Standard

Host of Electronic Brinell Hardness Tester: one unit

Control Cabinet: one unit

20X Reading Microscope (JC-10): one unit

Hard Alloy Indenter (Φ5 And Φ10): one of each

Hard Alloy Steel Ball (Φ5 And Φ10): one of each

Standard Brinell Hardness Blocks: two pieces

The above information provides the standard configuration. Actual specifications may vary according to custom requirements.
